Face sheet: 3003 aluminum alloy
Top finish: PVDF PE
Length: less than 12000mm
Width: less than 2200mm
Thickness: 6mm 8mm 10mm 12mm 15mm 20mm 25mm 50mm
Color: colors from Bolliya color chart or client customized color
Thermal conductivity U data: 5.57w/m2.k
Flame Expansion: BS476-7 s1
FR rated: GB8524-1997 FR A2
1. We can customize the specifications according to your needs.
2. The core can be PP honeycomb but also the aluminum honeycomb.
3. We use 3003 alloy which is more durable.
4. The aluminum honeycomb panel has better performance in the wind-resistance.
1. Liftinglug type
This installation method is the separation of lifting lug and honeycomb panel. After the lifting lug is processed separately, they are connected to the glue seam position of the honeycomb panel. The suitable width of the glue seam is ≥12mm. This installation method makes processing simple and easy to install.
2. Flanging type
This installation method is to process the flanging for installation when the aluminum honeycomb panel is processed. The installation only needs to be connected with the kneel and the glue seam. The suitable glue seam width is ≥10mm. This method is convenient for installation. However, the processing is slightly more complicated and is not suitable for modeling curtain wall panels.
3. Buckle type
This type is an aluminum buckle type, and the buckle is a specific profile, which is easy to install. However, this method requires high plate processing accuracy. It is not recommended to be used for panels with the length more than 3000mm. According to the width of the buckle, there are 20mm and 40mm stitches in the middle of the board.
If you are looking for aluminum honeycomb panel with preferable price and excellent quality, please contact our sales team.
